| 設計 | 2-driver, 2-way in-ceiling, SHOCK-MOUNT™ Isolation Mounting System, nylon-blended rigid baffle |
|
|
| 分頻點 | 2nd-order electro-acoustic at 2.5 kHz |
|
|
| 頻率響應 On-Axis | ±3 dB from 64 Hz - 22 kHz |
|
|
| 頻率響應 30° Off-Axis | ±3 dB from 64 Hz - 18 kHz |
|
|
| 高頻驅動器 | 1" (2.5cm) X-PAL™ dome, ferro-fluid damped / cooled, Reduced Edge Diffraction (RED™) Technology, Perforated Phase-Aligning (PPA™) Tweeter Lens |
|
|
| 中低音頻率驅動 | 8" (20.3cm) mineral-filled polypropylene cone, overmolded Active Ridge Technology (ART™) surround, die-cast aluminum chassis |
|
|
| 低頻率擴展 | 39 Hz |
|
|
| 靈敏度 Room / Anechoic | 92 dB / 88 dB |
|
|
| 阻抗 | Compatible with 8 ohms |
|
|
| 合適的放大器功率範圍 | 15-110 W |
|
|
| 最大輸入功率 | 80 W |
|
|
| 表面處理 | White, paintable grille, black/grey speaker |
|
|
| 重量 | 2.9 kg |
|
|
產品規格如有變更，以實際產品為主，恕不另行通知。
|
|
| 外形尺寸 | 26.1cm Diameter |
|
|
| 開孔尺寸 | 23.4cm Diameter |
|
|
| 最小安裝深度 | 9.8cm |
